- (2.0) Megapixel high-performance CMOS
- Analog HD output, up to 1080P resolution
- True Day/Night
- True WDR, up to 120dB
- EXIR technology, up to 80m IR distance
- IP67 weatherproof
- OSD Menu, DNR, Smart IR
- Up the Coax(HIKVISION-C)
- P.o.C
CAMERA
| Image Sensor | 2.0 megapixel progressive scan CMOS |
| Signal System | PAL/NTSC |
| Frame Rate | PAL: 1080p@25fps |
| NTSC: 1080p@30fps | |
| Effective Pixels | 1920(H)*1080(V) |
| Min. Illumination | Color: 0.005 Lux @ (F2.0, AGC ON), 0 Lux with IR |
| Shutter Time | PAL: 1/25 s to 1/50, 000 s |
| NTSC: 1/30 s to 1/50, 000 s | |
| Slow Shutter | Max. 16 times |
| Lens | 3.6 mm, 6 mm, 8 mm, 12 mm fixed focal lens |
| Lens Mount | M12 |
| Horizontal Field of View | 82.6°(3.6 mm), 54.4°(6 mm), 38°(8 mm), 24.4°(12 mm) |
| WDR | 120dB |
| Angle Adjustment | Pan: 0 - 360°, Tilt: 0 - 180°, Rotation: 0 - 360° |
| Day & Night | IR cut filter |
| Synchronization | Internal synchronization |
| Video Frame Rate | 1080P@25/30fps |
| HD Video Output | 1 Analog HD output |
| S/N Ratio | More than 62 dB |
MENU
| AGC | Supported |
| D/N Mode | Auto/Color/BW (Black and White) |
| White Balance | ATW, MANUAL |
| Privacy Mask | ON/OFF, 4 programmable privacy masks |
| Motion Detection | 4 programmable motion areas |
| Backlight Compensation | WDR/BLC/HLC/OFF |
| BLC | Supported |
| Language | Chinese/ English |
| Functions | Brightness, Sharpness, Mirror, Smart IR |
GENERAL
| Working | -40 °C – 60 °C (-40 °F – 140 °F) |
| Temperature/Humidity | Humidity 90% or less (non-condensing) |
| Power Supply | 12V DC ±25%/ P.o.C |
| Power Consumption | Max. 5.8W |
| Weather Proof Ratings | IP67 |
| Material | Metal |
| IR Range | Up to 80m |
| Communication | Up the coax, Protocol: HIKVISION-C (TVI output) |
| Dimension | 86.7 mm × 81.6 mm × 226 mm (3.41" × 3.23" × 8.67") |
| Weight | 1.5 lb (680 g) |
