- 2.0 Megapixel high-performance CMOS
- Analog HD output, up to 1080P resolution
- True Day/Night
- True WDR, up to 120dB
- EXIR technology, up to 20m IR distance
- IP67 weatherproof
- OSD Menu, DNR, Smart IR
- Up the Coax(HIKVISION-C)
- Cấp nguồn qua cáp P.o.C af
CAMERA
| Image Sensor | 2.0 megapixel progressive scan CMOS |
| Signal System | PAL/NTSC |
| Frame Rate | PAL: 1080p@25fps |
| NTSC: 1080p@30fps | |
| Effective Pixels | 1928(H)*1088(V) |
| Min. Illumination | Color: 0.005 Lux @ (F2.0, AGC ON), 0 Lux with IR |
| Shutter Time | PAL: 1/25 s to 1/50, 000 s |
| NTSC: 1/30 s to 1/50, 000 s | |
| Slow Shutter | Max. 16 times |
| Lens | 2.8 mm, 3.6 mm, 6 mm fixed focal lens |
| Lens Mount | M12 |
| Horizontal Field of View | 103°(2.8mm), 82.2°(3.6mm), 54°(6mm) |
| WDR | 120dB |
| Angle Adjustment | Pan: 0 - 360°, Tilt: 0 - 75°, Rotation: 0 - 360° |
| Day & Night | IR cut filter |
| Synchronization | Internal synchronization |
| Video Frame Rate | 1080P@25/30fps |
| HD Video Output | 1 Analog HD output |
| S/N Ratio | More than 62 dB |
MENU
| AGC | Supported |
| D/N Mode | Auto/Color/BW (Black and White) |
| White Balance | ATW, MANUAL |
| Privacy Mask | ON/OFF, 4 programmable privacy masks |
| Motion Detection | 4 programmable motion areas |
| Backlight Compensation | WDR/BLC/HLC/OFF |
| 3D DNR (Digital Noise Reduction) | Level 1 to 10 |
| BLC | Supported |
| Language | Chinese/ English |
| Functions | Brightness, Sharpness, Mirror, Smart IR |
GENERAL
| Working | -40 °C – 60 °C (-40 °F – 140 °F) |
| Temperature/Humidity | Humidity 90% or less (non-condensing) |
| Power Supply | 12V DC ±25% PoC.af |
| Power Consumption | Max. 3.6W |
| Weather Proof Ratings | IP67 |
| Material | Metal |
| IR Range | Up to 20m |
| Communication | Up the coax, Protocol: HIKVISION-C (TVI output) |
| Dimension | 91 mm × 82.6 mm × 68.3 mm (3.58" × 3.25" × 2.69") |
| Weight | 0.77 lb (350 g) |
