- Embedded processor
- H.264+/H.264 dual-stream video compression
- Supports HDCVI/AHD/TVI/CVBS/IP video inputs
- Max 16 channels IP camera inputs, each channel up to 5MP
- Max 64Mbps Incoming Bandwidth
- Smart Search and Intelligent Video System
- Warranty 2 years
SYSTEM
| Main Processor | Embedded Processor |
| Operating System | Embedded LINUX |
VIDEO AND AUDIO
| Analog Camera Input | N/A |
| HDCVI Camera Input | 32 Channel |
| AHD Camera | N/A |
| TVI Camera | N/A |
| CVBS Camera | N/A |
| IP Camera Input | 16 Channel, each channel up to 5MP |
| Audio In/Out | 4/1 |
| Two-way Talk | 01 Mic In, 01 Mic Out, BNC |
RECORDING
| Video Compression | H.264+/ H.264 |
| Resolution | 1080P, 720P, 960H, D1, HD1, BCIF, CIF, QCIF |
| Record Rate | Main stream: 1080P(1~15fps) 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps) |
| Sub Stream: D1/CIF/QCIF(1~15fps) | |
| Video Bit Rate | 1Kbps ~ 6144Kbps Per Channel |
| Record Mode | Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
| Record Interval | 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
| Audio Compression | N/A |
| Audio Sample Rate | N/A |
| Audio Bit Rate | N/A |
DISPLAY
| Interface | 02 HDMI, 01 VGA, 01 TV |
| Resolution | 1920×1080, 1280×1024, 1280×720, 1024×768 |
| Multi-screen Display | 1/4/8/9/16/25/36 |
| OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
NETWORK
| Interface | 1 RJ-45 Port (1000M) |
| Network Function | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Supports Dahua IP camera, DVR, NVS, etc.) |
| Max. User Access | 128 users |
| Smart Phone | iPhone, iPad, Android |
| Interoperability | ONVIF 2.4.1, CGI Conformant |
VIDEO DETECTION AND ALARM
| Trigger Events | Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis |
| Alarm input | 16 |
| Relay Output | 6 |
| Tracking Trigger Event | N/A |
PLAYBACK AND BACKUP
| Playback | 1/4/9/16 |
| Search Mode | Time /Date, Alarm, MD and Exact Search (accurate to second), Smart Search |
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode | USB Device/Network |
STORAGE
| Internal HDD | 04 SATA Ports, up to 08TB capacity for each disk |
| HDD Mode | Single |
| eSATA | 01 Port |
AUXILIARY INTERFACE
| Front Cover | N/A |
| USB | 01 USB 2.0, 02 USB 3.0 |
| RS232 | 01 port, for PC communication & Keyboard |
| RS485 | 01 Port, for PTZ Control |
ELECTRICAL
| Power Supply | AC100V-240V, 50/60Hz |
| Power Consumption (Without HDD) | <30W |
GENERAL
| Dimensions | 1.5U, 440mm×417mm×76mm (17.3"x 16.4" x 3.0") |
| Net Weight (without HDD) | 6kg (13.23lb) |
| Gross Weight | 7kg (15.43lb) |
| Installation | Desktop installation |
| Operating Conditions | -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa |
| Storage Conditions | 0°C ~ +50°C (+32°F ~ +122°F), 0 ~ 90% RH |
| Third-party Support | Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
| Certifications | FCC: Coming Soon |
| CE: N/A | |
| CE-EMC: N/A | |
| UL: Coming Soon |
