- H.264+ & Dual-stream video compression
- Support HD-TVI/analog/AHD/IP camera triple hybrid
- Support both HD-TVI and analog cameras with
adaptive access
- Full channel@5MP resolution non real-time recording
- HDMI output at up to 4K while VGA output at up to 1920×1080P
resolution
- Long transmission distance over coax cable
- Support up to 8-ch synchronous playback
VIDEO/ AUDIO INPUT
Analog video input | 8-ch |
BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection | |
Turbo HD input | 5 MP20, 5 MP12, 4 MP25, 4 MP30, 3 MP18 , 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25, NTSC, PAL |
Supported AHD input | 1080p25, 1080p30, 720p25, 720p30 |
CVBS input | Supported |
IP video input | 2-ch |
Up to 4MP resolution | |
Audio input/ Two-way audio input |
4-ch, RCA (2.0 Vp-p, 1 KΩ) |
VIDEO/AUDIO OUTPUT
CVBS output | 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 | ||
HDMI/VGA output | VGA: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz | ||
HDMI: 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz | |||
Encoding resolution | 5 MP/ 4 MP/ 3MP/1080p/720p/WD1/4CIF/VGA/CIF | ||
Frame rate | Main Stream | 5 MP@10fps/4 MP@15fps/3 MP@15fps 1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) | |
Sub Stream | WD1/4CIF/2CIF@12fps; CIF/QVGA/QCIF@25fps (P)/30fps (N) | ||
Video bit rate | 32 Kbps to 10 Mbps | ||
Audio output | 1-ch, RCA (Linear, 1 KΩ) | ||
Audio bit rate | 64Kbps | ||
Dual Stream | Supported | ||
Stream type | Video, Video & audio | ||
Synchronous playback | 8-ch |
NETWORK MANAGEMENT
Incoming bandwidth | |
Remote connections | 128 |
Network protocols | TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
ENCODING
Video compression standard |
H.264+/H.264 |
Frame rate | 25fps(P)/30fps(N) |
Video bit rate | 32 Kbps to 4 Mbps |
Stream type | Video & Audio/Video |
Dual-stream | Supported |
Audio compression standard | G.711u |
Audio bit rate | 64 Kbps |
Synchronous playback | 8-ch |
HARD DISK
Sata | 1 SATA interface |
Capacity | Up to 6TB capacity for each disk |
EXTERNAL INTERFACE
Two-way audio input |
1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the 1st audio input) |
Network interface | 1: RJ45 10M/100M/1000M self-adaptive Ethernet interface |
USB interface | Real panel: 1 × USB 3.0; Front panel: 1 × USB 2.0 |
Serial interface | RS-485 (half-duplex) |
Alarm in/out | 8/4 |
GENERAL
Power supply | 12V AC |
Consumption (without hard disks) | ≤ 15W |
Working temperature | -10ºC to +55ºC (14ºF to 131ºF) |
Working Humidity | 10% to 90% |
Dimensions | 315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch) |
Weight (without hard disks) | Approximate 2 Kg (4.4 lb) |
