- 16-ch video & 1-ch audio input
- HD-TVI/analog/AHD/IP camera quadruple hybrid
- Full channel real-time recording at 1080P resolution
- HDMI output at up to 4K (3840 × 2160) resolution
- Long transmission distance over coax cable
- Front panel and alarm I/O optional
- Playback at up to 256X speed.
VIDEO/ AUDIO INPUT
| Analog video input | 16-ch |
| BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection | |
| Supported HD TVI input | 3 MP, 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60 |
| Note: The 3 MP signal input is only available for the first 2 channels of DS-7208HQHI-F1/N | |
| Supported AHD input | 1080p25, 1080p30, 720p25, 720p30 |
| CVBS input | Supported |
| IP video input | 2-ch |
| Up to 1080p resolution | |
| Audio input/ Two-way audio input |
1-ch, RCA (2.0 Vp-p, 1 KΩ) |
VIDEO/AUDIO OUTPUT
| CVBS output | 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 | ||
| HDMI/VGA output | HDMI: 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz | ||
| VGA: 1-ch, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz | |||
| Encoding resolution | When 1080p Lite mode not enabled: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF | ||
| When 1080p Lite mode enabled: 3 MP/1080p lite/720p/VGA/WD1/4CIF/CIF | |||
| Frame rate | Main Stream | When 1080p Lite mode not enabled: | |
| - For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@12fps | |||
| - For 1080p stream access: 1080p/720p@12fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) | |||
| - For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) | |||
| When 1080p Lite mode enabled: 3 MP/1080p lite/720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) | |||
| Sub Stream | WD1/4CIF/2CIF@12fps; CIF/QVGA/QCIF@25fps (P)/30fps (N) | ||
| Video bit rate | 32 Kbps to 6 Mbps | ||
| Audio output | 1-ch, RCA (Linear, 1 KΩ) | ||
| Audio bit rate | 64Kbps | ||
| Dual Stream | Supported | ||
| Stream type | Video, Video & audio | ||
| Synchronous playback | 16-ch | ||
NETWORK MANAGEMENT
| Remote connections | 128 |
| Network protocols | TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
ENCODING
| Video compression standard |
H.264+/H.264 |
| Frame rate | 25fps(P)/30fps(N) |
| Video bit rate | 32 Kbps to 4 Mbps |
| Stream type | Video & Audio/Video |
| Dual-stream | Supported |
| Audio compression standard | G.711u |
| Audio bit rate | 64 Kbps |
| Synchronous playback | 16-ch |
HARD DISK
| Sata | 1 SATA interface |
| Capacity | Up to 6TB capacity for each disk |
EXTERNAL INTERFACE
| Network interface | 1: RJ45 10M/100M/1000M self-adaptive Ethernet interface |
| USB interface | Front panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0 |
GENERAL
| Power supply | 12V DC |
| Consumption (without hard disks) | ≤ 30W |
| Working temperature | -10ºC to +55ºC (14ºF to 131ºF) |
| Working Humidity | 10% to 90% |
| Chassis | 260 mm chassis |
| Dimensions | 315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch) |
| Weight (without hard disks) | Approximate 2 Kg (4.4 lb) |
