- 1/2.7" (2.0) Megapixel high-performance CMOS
- Analog HD output, up to 1080P resolution
- 2.8 mm to 12 mm Motorized Vari-Focal Lens
- True Day/Night
- True WDR, up to 120dB
- EXIR technology, up to 40m IR distance
- IP66 weatherproof
- OSD Menu, DNR, Smart IR
- Up the Coax(HIKVISION-C)
CAMERA
| Image Sensor | 1/2.7" (2.0MP) CMOS Image Sensor |
| Signal System | PAL/NTSC |
| Effective Pixels | 1928(H)*1088(V) |
| Min. Illumination | 0.01 lux @ ƒ/1.2, AGC on, 0 lux with IR |
| Shutter Time | 1/25(1/30) s to 1/50,000 s |
| Lens | Motorized VF lens, 2.8 mm to 12 mm |
| Lens Mount | φ14 |
| Angle of View | 35.1° to 114.5° |
| WDR | 120dB |
| Angle Adjustment | Pan: 0 - 360°, Tilt: 0 - 75°, Rotation: 0 - 360° |
| Day & Night | ICR |
| Synchronization | Internal synchronization |
| Video Frame Rate | 1080P@25/30fps |
| HD Video Output | 1 Analog HD output |
| S/N Ratio | More than 62 dB |
MENU
| AGC | Supported |
| D/N Mode | Color/BW/SMART |
| White Balance | ATW, MWB |
| BLC | Supported |
| Language | Chinese/ English |
| Functions | Wide Dynamic Range, Digital noise reduction, Mirror, SMART IR |
GENERAL
| Working | -40 °C – 60 °C (-40 °F – 140 °F) |
| Temperature/Humidity | Humidity 90% or less (non-condensing) |
| Power Supply | 12 VDC±15% |
| Power Consumption | Max. 6W |
| Weather Proof Ratings | IP66 |
| IR Range | Up to 40m |
| Communication | Up the coax, Protocol: HIKVISION-C (TVI output) |
| Dimension | 5.29" × 4.88" × 4.39" (134.3 mm × 123.9 mm × 111.4 mm) |
| Weight | Approximately 1.57 lb (750 g) |
