- 2.0 Megapixel high-performance CMOS
- Analog HD output, up to 1080P resolution
- True Day/Night
- 3D DNR, Smart IR
- True WDR, up to 120dB
- EXIR technology, up to 20m IR distance
- IP66 weatherproof
- OSD Menu Controlled via UTC
- Up the Coax(HIKVISION-C)
CAMERA
| Image Sensor | 2MP CMOS Image Sensor |
| Signal System | PAL/NTSC |
| Effective Pixels | 1928(H)*1088(V) |
| Min. Illumination | Color: 0.01 lux @ (ƒ/1.2, AGC on); B/W: 0.001 lux @ (ƒ/1.2, AGC on) |
| Shutter Time | 1/25(1/30) s to 1/50,000 s |
| Lens | 2.8mm, 3.6mm, 6mm optional |
| Lens Mount | M12 |
| Angle of View | 103°(2.8mm), 82.2°(3.6mm), 54°(6mm) |
| WDR | 120dB |
| Angle Adjustment | Pan: 0 - 360°, Tilt: 0 - 90°, Rotation: 0 - 360° |
| Day & Night | ICR |
| Synchronization | Internal synchronization |
| Video Frame Rate | 1080P@25/30fps |
| HD Video Output | 1 Analog HD output |
| CVBS Output | 1Vp-p Composite Output(75Ω/BNC) |
| S/N Ratio | More than 62 dB |
MENU
| AGC | Supported |
| D/N Mode | Color/BW/SMART |
| White Balance | ATW, MWB |
| BLC | Supported |
| Language | Chinese/ English |
| Functions | Wide Dynamic Range, Digital noise reduction, Mirror, SMART IR |
GENERAL
| Working | -40 °C – 60 °C (-40 °F – 140 °F) |
| Temperature/Humidity | Humidity 90% or less (non-condensing) |
| Power Supply | 12 VDC±15% |
| Power Consumption | Max. x5W |
| Weather Proof Ratings | IP66 |
| IR Range | Up to 20m |
| Communication | Up the coax, Protocol: HIKVISION-C (TVI output) |
| Dimension | 58.5mm×55.5mm×153.6mm (2.30”×2.19”×6.05”) |
| Weight | Approx. 370g (0.82lb) |
