CAMERA
Image Sensor | 2MP CMOS Image Sensor |
Signal System | PAL/NTSC |
Frame Rate | PAL: 1080p@25fps; NTSC: 1080p@30fps |
Effective Pixels | 1920 (H) ×1080 (V) |
Min. Illumination | 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR |
Shutter Time | 1/25(1/30) s to 1/50,000 s |
Lens | 2.8 mm, 3.6 mm, 6 mm fixed lens |
Horizontal Field of View | 103 ° (2.8 mm), 82.2 ° (3.6 mm), 54 ° (6 mm) |
Lens Mount | M12 |
Angle Adjustment | Pan: 0 - 360°, Tilt: 0 - 75°, Rotation: 0 - 360° |
Day & Night | IR cut filter |
Synchronization | Internal synchronization |
Video Frame Rate | 720p@25fps/720p@30fps |
MENU
AGC | Low/middle/high |
Day/Night Mode | Smart/color/BW(Black and White) |
Backlight Compensation | Yes |
DWDR | Yes |
Language | English, Chinese |
Functions | Brightness, Sharpness, DNR, Mirror |
INTERFACE
Video Output | 1 HD analog output |
GENERAL
Working | -20 °C - 45 °C (-4 °F - 113 °F) |
Temperature/Humidity | Humidity 90% or less (non-condensing) |
Power Supply | 12V DC ±15% |
Power Consumption | Max. 4W |
Material | Plastic |
IR Range | Up to 20m |
Dimension | Φ89.5 × 69.8 mm(Φ3.52” × 2.75”) |
Weight | Approx. 250 g (0.55 lb.) |
