- 2.0 Megapixel high-performance CMOS
- Analog HD output, up to 1080P resolution
- HD-TVI Technology
- True Day/Night
- 3D DNR, Smart IR
- True WDR, up to 120dB
- up to 110m IR distance
- IP66 weatherproof
- OSD Menu Controlled via UTC
- Alarm Input and Output
CAMERA
Image Sensor | 1/3" progressive scan CMOS |
Signal System | PAL/NTSC |
Effective Pixels | 1920 x 1080 |
Min. Illumination | Color: 0.01 lux @ (ƒ/1.2, AGC on); B/W: 0.001 lux @ (ƒ/1.2, AGC on) |
Shutter Time | 1/25(1/30) s to 1/50,000 s |
Lens | |
Lens Mount | C/CS mount |
Angle of View | 59.8°-6.2° |
WDR | 120dB |
Angle Adjustment | Pan: 0 - 360°, Tilt: 0 - 90°, Rotation: 0 - 360° |
Day & Night | ICR |
Synchronization | Internal synchronization |
Video Frame Rate | 1080P@25/30fps |
HD Video Output | 1 Analog HD output |
CVBS Output | 1Vp-p Composite Output(75Ω/BNC) |
S/N Ratio | More than 52 dB |
MENU
Camera ID | On/off (15 characters, position programmable) |
AGC | Supported |
D/N Mode | Color/BW/EXT |
White Balance | ATW, AWC-SET, indoor, outdoor, manua |
Privacy Mask | On/Off, maximum 8 zones |
Motion Detection | On/Off, maximum 4 zones |
BLC | Supported |
Anti-flicker | On/off |
Language | Chinese/ English |
Functions | HSBLC (Eclipse), digital noise reduction, digital zoom (62x), slow shutter, mirror, defog, defect pixel correction, SMART D-ZOOM |
Scene | Indoor/ Outdoor/ Indoor1/ LOW-LIGHT |
GENERAL
Working | -30° C to 60° C (-22° F to 140° F) |
Temperature/Humidity | Humidity 90% or less (non-condensing) |
Power Supply | 24 VAC, 12 VDC |
Power Consumption | Max. 3.5W |
Weather Proof Ratings | IP66 |
IR Range | Up to 110m |
Communication | Up-the-Coax (need UTC controller) Protocol: Pelco-C |
Dimension | 69.8 mm × 58 mm ×145 mm (2.68" × 2.56" × 5.70") |
Weight | 830 g (1.83 lbs) |
