- Embedded processor
- H.264 video compression
- Support HDCVI/AHD/TVI/CVBS/IP video inputs
- Max 5/10 channels IP camera inputs
- Long transmission distance over coax cable
- Supports 01 SATA HDD, up to 08TB
- Warranty 02 years
SYSTEM
Main Processor | Embedded Processor |
Operating System | Embedded LINUX |
VIDEO AND AUDIO
Analog Camera Input | 08 Channel, BNC |
HDCVI Camera | 1080P@25/30fps, 720P@25/30fps |
AHD Camera | 1080P@25/30, 720P@25/30fps |
TVI Camera | 1080P@25/30, 720P@25/30fps |
CVBS Camera | PAL / NTSC |
IP Camera Input | 8+2, each channel up to 5.0MP |
Audio In/Out | 1/1, RCA |
Two-way Talk | Reuse audio in/out, RCA |
RECORDING
Video Compression | H.264 |
Resolution | 1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF |
Record Rate | Main stream: 8CH:1080N(1~12fps)/720P(1~15fps)/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps) |
Sub steram: 8CH:CIF/QCIF(1~7fps) | |
Video Bit Rate | 1Kbps ~ 6144Kbps Per Channel |
Record Mode | Manual, Schedule (General, Continuous), MD (Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
Record Interval | 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec |
Audio Compression | N/A |
Audio Sample Rate | N/A |
Audio Bit Rate | N/A |
DISPLAY
Interface | 1 HDMI ,1 VGA |
Resolution | 1920×1080, 1280×1024, 1280×720 |
Multi-screen Display | When IP extension mode not enabled: 8CH: 1/4/8/9 |
When IP extension mode enabled: 8CH: 1/4/8/9/16 | |
OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
NETWORK
Interface | 1 RJ-45 Port (100M) |
Network Function | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Supports Dahua IP camera, DVR, NVS, etc.) |
Max. User Access | 128 users |
Smart Phone | iPhone, iPad, Android |
Interoperability | ONVIF 2.42, CGI Conformant |
VIDEO DETECTION AND ALARM
Trigger Events | Recording, PTZ, Tour, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss, Tampering and Diagnosis |
Alarm input | N/A |
Relay Output | N/A |
PLAYBACK AND BACKUP
Playback | 08CH: 1/4/9 |
Search Mode | Time /Date, Alarm, MD and Exact Search (accurate to second) |
Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
Backup Mode | USB Device/Network |
STORAGE
Internal HDD | 1 SATA Port, up to 08TB capacity |
eSATA | N/A |
AUXILIARY INTERFACE
USB | 2 USB 2.0 |
RS232 | N/A |
RS485 | N/A |
ELECTRICAL
Power Supply | DC12V/2A |
Power Consumption (Without HDD) | <10W (without HDD) |
GENERAL
Dimensions | Smart 1U, 205mm×211mm×45mm (8.1“×8.3”×1.8“) |
Net Weight (without HDD) | 0.55kg (1.2lb) (without HDD) |
Gross Weight | 1kg (2.2lb) |
Installation | Desktop installation |
Operating Conditions | -10°C ~ +55°C (+14°F ~ +131°F), 10~ 90% RH |
Storage Conditions | -20°C ~ +70°C (-4°F ~ +158°F) , 0~ 90% RH |
Third-party Support | Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
Certifications | FCC: Part 15 Subpart B |
CE: CE-LVD: EN 60950-1/IEC 60950-1 | |
CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 | |
UL: UL 60950-1 |
