FEATURES :
SPECIFICATION
| INPUT | Voltage | 100V / 110V /115V / 120V ±25% |
| 220V /230V / 240V ±25% | ||
| Frequency | 50Hz / 60Hz ±10% autosensing | |
| OUTPUT | Voltage (Backup mode) |
100V / 110V /115V / 120V (±5% on battery) |
| 220V /230V / 240V (±5% on battery) | ||
| AVR | AVR with 1 step boost and 1 step back | |
| Frequency (Backup mode) |
50Hz / 60Hz ±1% | |
| Waveform | Simulated sine wave | |
| Connections | *Please refer below "Receptacle Options". The customized receptacle can be discussed. | |
| Transfer time | 2 to 4 millisecond including detection time (typical) | |
| PROTECTION | Overload | UPS automatic power off if overload exceeds 110% of nominal at 60 seconds; 130% at 3 seconds |
| Unit Input | * Optional - Fuse or overload & short circuit protection | |
| Telecommunication | * Optional - none or RJ45 | |
| Alarm | Buzzer beeps under backup mode, battery low, battery charging fault, and overload | |
| BATTERY | Type | Sealed, maintenance-free lead acid battery |
| Typical recharge time | 3-4 hours to 90% | |
| Battery quantity | 12V 9Ah x1 | |
| Protection | Automatic diagnostics, over-discharge and short circuit protection | |
| STANDARDS | Dimension (W x D x H) |
100mm x 278mm x 140mm |
| Net weight | 5.4kg | |
| Display | LED indicator | |
| Communication interface | * Optional - none or USB B-type | |
| Audible noise | < 40dBA (1m from surface) | |
| Ambient operation | Maximum elevation at 2000m, 0 to 40℃, 0 to 95% humidity (non-condensing) | |
| Storage condition | Maximum 2000m | |
| Capacity | 1000VA/600W | |
