- 3.0 megapixel high resolution
- 180° Horizontal FOV
- IR range: up to 10m
- H.265+, H.265
- Built-in microphone and speaker, support two-way audio
- Built-in Wi-Fi
- Built-in Micro SD/SDHC/SDXC slot, up to 128G
CAMERA
| Image Sensor | 1/2.8" Progressive Scan CMOS |
| Min. Illumination | 0.01Lux @ (F1.2, AGC ON), 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Slow Shutter | Support |
| Day &Night | IR cut filter |
| DNR | 3D DNR (Digital Noise Reduction) |
| Wide Dynamic Range | Digital WDR |
| 3-Axis Adjustment | Pan: 0° to 360°, tilt: -75° to 65°, rotate: 0° to 360° |
LENS
| Focal length | 1.68 mm |
| Aperture | F2.0 |
| FOV | Horizontal field of view: 180°, Vertical field of view: 85° |
| Lens Mount | Φ12 |
IR
| IR Range | 10 m |
| Wavelength | 850nm |
COMPRESSION STANDARD
| Video Compression | Main stream: H.265/H.264 |
| Sub stream: H.265/H.264/MJPEG | |
| H.264 Type | Main Profile/High Profile |
| H.264+ | Yes |
| H.265 Type | Main Profile |
| H.265+ | Yes |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| Audio Compression | G722.1/G711ulaw/G711alaw/G726/MP2L2/PCM |
| Audio Bit Rate | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2) |
| Max. Resolution | 2304 × 1296 |
| Main Stream Max. Frame Rate | 50Hz: 20fps (2304 × 1296), 25fps (1920 × 1080, 1280 × 720) |
| 60Hz: 20fps (2304 × 1296), 30fps (1920 × 1080, 1280 × 720) | |
| Sub Stream Max. Frame Rate | 50Hz: 25fps(640 × 360, 480 × 272, 432 × 240) |
| 60Hz: 30fps(640 × 360, 480 × 272, 432 × 240) | |
| Image Setting | Saturation, brightness, contrast, sharpness adjustable by client software or web browser |
| Day/Night Switch | Support auto/scheduled |
| Image Enhancement | BLC/3D DNR |
| Region of Interest | Support 1 fixed region for each stream |
AUDIO
| Environment Noise Filter | Support |
| Audio Sampling Rate | 16 kHz, 32kHz, 44.1kHz, 48kHz |
NETWORK
| Network Storage | Support Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Detection | Motion Detection |
| Alarm Trigger | Video Tampering Alarm, HDD Full, HDD Error, Network Disconnected, IP Address Conflicted, Illegal Login |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, IGMP, QoS, IPv6 |
| Standard | ONVIF (PROFILE S, PROFILE G), ISAPI |
| Simultaneous Live View | Up to 6 channels |
| User/Host | Up to 32 users |
| 3 levels: Administrator, Operator and User | |
| Client | iVMS-4200, Hik-Connect, iVMS-5200 |
| General Function | One-key reset, anti-flicker, dual streams, heartbeat, password protection, privacy mask, watermark |
INTERFACE
| On-board Storage | Built-in microSD/SDHC/SDXC slot, up to 128 GB |
| Audio Interface | 1 build-in microphone, 1 build-in speaker, two-way audio, mono sound |
| Reset | Yes |
| SVC | Support H.264 and H.265 encoding |
WI-FI
| Wireless Standards | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4 GHz - 2.4835 GHz |
| Channel Bandwidth | 20/40MHz Support |
| Protocols | 802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM/64-QAM, 16-QAM, QPSK, BPSK |
| Security | WPA/WPA, WPA-PSK/WPA2-PSK, WPS |
| Transfer Rates | 11b: 11Mbps, 11g: 54Mbps, 11n: up to 150Mbps |
| Wireless Range | 50 meters (The performance varies based on actual environment) |
GENERAL
| Working | -10 °C to 40°C (14 °F to 104 °F) |
| Temperature/Humidity | Humidity 95% or less (non-condensing) |
| Power Supply | 5V DC ± 10%, micro USB interface |
| Power Consumption | 5 VDC, 1A; Max. 6.5W |
| Interface Protection | TVS 2000V Lightning Protection, Surge Protection and Voltage Transient Protection |
| Material | Bracket: metal; Camera shell: plastic |
| Dimension | Φ78.1 mm × 110.2 mm (Φ3.07" × 4.34") |
| Weight | Camera: Approx. 230 g (0.51 lb.) |
