CAMERA
| Image Sensor | 1/1.8" Progressive Scan CMOS |
| Min. Illumination | 0.05 lux @ (F1.2, AGC ON) |
| 0.3 lux @ (F2.8, AGC ON ) 0 lux with IR | |
| Shutter Speed | 1/25 s to 1/100,000 s |
| Lens | 1.27mm @F2.8 |
| Lens Mount | Φ12 |
| Angle of view | 360° |
| Day &Night | IR cult filter with auto switch |
| DNR | 3D DNR |
| WDR | 120dB |
COMPRESSION STANDARD
| Video Compression | H.264/MJPEG |
| H.264 Type | Baseline Profile / Main Profile / High Profile |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| Max. Resolution | 3072 x 2048 |
| Frame Rate | High-frame Mode: support 50Hz: 1 x fisheye (3072 x 2048, 25fps) or (2048 x 2048, 25fps) or 4 x PTZ at (1024 x 768, 30fps) 60Hz: 1 x fisheye (3072 x 2048, 25fps) or (2048 x 2048, 30fps) or 4 x PTZ at (1024 x 768, 30fps) |
| Multi-channel Mode: support 50Hz: 1 x fisheye (1280 x 1280, 12.5fps) and 1 x panoramic (2048 x 1536, 12.5fps) and 3 x PTZ (1024 x 768, 12.5fps) 60Hz: 1 x fisheye (1280 x 1280, 15fps) and 1 x panoramic (2048 x 1536, 15fps) and 3 x PTZ (1024 x 768, 15fps) | |
| Number of Streams | High Frame Rate Mode: 1 or 4 |
| Multi-Channel: up to 5 (No sub-streams) | |
| Image Setting | Saturation, Brightness, Contrast, Hue, Sharpness, AGC, White Balance |
| Day/Night Switch | Auto/ Scheduled/ Manual |
| High Light Compensation | Support |
NETWORK
| Network Storage | NAS, SAMB / CIFS |
| Alarm Trigger | Motion detection, dynamic analysis, tamper alarm, network disconnect, IP address conflict, storage full, storage error |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Standard | ONVIF, PSIA, CGI |
| General Function | User Authentication, Watermark, IP address filtering, Anonymous access |
INTERFACE
| Communication Interface | 1 RJ45 10M/100M/1000M Ethernet interface |
| On-board Storage | Built-in microSD/SDHC/SDXC slot, up to 64GB |
GENERAL
| Working | -30 °C – 60 °C (-22 °F – 140 °F) |
| Temperature/Humidity | Humidity 95% or less (non-condensing) |
| Power Supply | 12 VDC ± 10% , PoE (802.3af) |
| Power Consumption | Max. 11W |
| IR Range | Up to 10m |
| Protection | IK10 |
| Dimension | 164 x 152.8 x 43.8mm (6.46” x 6.02” x 1.72”) |
| Weight | Approx. 1400g (3,09 lb.) |
