CAMERA
| Image Sensor | 1/2.5" Progressive Scan CMOS |
| Min. Illumination | Color: 0.01lux @(F1.2, AGC ON) |
| 0 lux with IR on | |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Lens | 1.05 mm @ F2.2 |
| Lens Mount | Φ12 |
| Angle of view | horizontal field of view: 180°, vertical field of view: 180° |
| Day &Night | IR cult filter with auto switch |
| DNR | 3D DNR |
| WDR | 120dB |
COMPRESSION STANDARD
| Video Compression | Main stream: H.265/H.264 |
| Sub stream: H.265/H.264/MJPEG | |
| H.264 Type | Main Profile/High Profile |
| H.264+ | Support |
| H.265 Type | Main Profile |
| H.265+ | Support |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| Audio Compression | G.711/G.722.1/G.726/MP2L2 |
| Audio Bit Rate | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-128Kbps(MP2L2) |
| Max. Resolution | 2560 × 1920 |
| Main Stream Max. Frame Rate | 50Hz: 25fps (2560 × 1920, 2048 × 1536, 1280 × 960) |
| 60Hz: 30fps (2560 × 1920, 2048 × 1536, 1280 × 960) | |
| Sub Stream Max. Frame Rate | 50Hz: 25fps (352× 288, 704 × 576) |
| 60Hz: 30fps (352 × 240, 704 × 576) | |
| Image Setting | Saturation, brightness, contrast, and sharpness are adjustable via client software or web browser |
| Day/Night Switch | Auto/ Scheduled/ Triggered by Alarm In |
| Image Enhancement | WDR/3D DNR/Backlight Compensation/Defog |
| ROI | Support 1 fixed region for each stream |
| Lens Distortion Correction | Support |
| Target Cropping | Support |
LIVE VIEW DISPLAY
| Mount Type | Support table, wall, and ceiling |
| Display Mode | Support 14 display modes in total (including display modes of different mount types): Fisheye View, 180 Panorama View, 4PTZ, Fisheye + 3PTZ, 360 Panorama View, 360 Panorama + PTZ, 360 Panorama + 3PTZ, 360 Panorama + 6PTZ, 360 Panorama + 8PTZ, 2PTZ, Fisheye + 8PTZ, Panorama View, Panorama + 3PTZ, Panorama + 8PTZ |
AUDIO
| Environment Noise Filtering | Support |
| Audio I/O | Support |
| Sampling Rate | Max. 48kHz |
NETWORK
| Network Storage | NAS (Support NFS,SMB/CIFS), built-in microSD/SDHC/SDXC card slot, up to 128 G, ANR |
| Detection | Motion detection, dynamic analysis, intrusion detection, line crossing detection |
| Alarm Trigger | Video tampering alarm, HDD full, HDD error, network disconnected, IP address conflicted, illegal login |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 |
| Standard | ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| General Function | One-key reset, anti-flicker, fassword protection, privacy mask, IP Address filtering, heartbeat, watermark |
INTERFACE
| Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet interface |
| Audio | 1 audio input (line in), 1 audio output interface |
| Alarm | 1 alarm input, 1 alarm output (DC24V, 1A or AC110V, 500mA, max.) |
| On-board Storage | Built-in microSD/SDHC/SDXC slot, up to 128GB |
GENERAL
| Working | -10 °C to 50°C (14 °F to 122 °F) |
| Temperature/Humidity | Humidity 95% or less (non-condensing) |
| Power Supply | 12 VDC ± 25% , PoE (802.3af, class 3) |
| Power Consumption | Max. 6.7W |
| IR Range | Up to 8 m |
| Dimension | Φ 119.9 × 41.2 mm (Φ 4.72″ × 1.62″) |
| Weight | Approx. 600g g (1,32 lb.) |
