CAMERA
| Image Sensor | 1/3″ CMOS |
| Effective Pixels | 2688(H)×1520(V), 4.1MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/4s~1/100,000s |
| NTSC: 1/3s~1/100,000s | |
| Minimum Illumination | 0.01Lux/F1.5, 30IRE, 0Lux IR on |
| S/N Ratio | More than 65dB |
| IR Distance | Up to 30m (98 feet) |
| IR On/Off Control | Auto / Manual |
| IR LEDs | 12 |
| Pan | 0° ~ 360° |
| Tilt | 0° ~ 90° |
| Rotation | 0° ~ 360° |
LENS
| Lens Type | Fixed lens / Fixed iris |
| Mount Type | Board-in |
| Focal Length | 3.6mm (2.8mm, 6mm Optional) |
| Max Aperture | F1.5 |
| Angle of View | H: 79° (99.7°/48.6°) |
| Focus Control | N/A |
| Close Focus Distance | 1500mm (900mm, 1700mm) |
| 59.06” (35.43”, 66.93”) |
DORI DISTANCE
| Distance | ||
| Detect |
25px/m - (8px/ft) |
2.8mm: 63m(208ft) |
| 3.6mm: 80m(262ft) | ||
| 6mm:120m(394ft) | ||
| Observe | 63px/m - (19px/ft) | 2.8mm: 25m(83ft) |
| 3.6mm: 32m(105ft) | ||
| 6mm:48m(157ft) | ||
| Recognize | 125px/m - (38px/ft) | 2.8mm: 13m(42ft) |
| 3.6mm: 16m(53ft) | ||
| 6mm: 24m(79ft) | ||
| Identify | 250ppm - (76px/ft) | 2.8mm: 6m(21ft) |
| 3.6mm: 8m(26ft) | ||
| 6mm: 12m(39ft) | ||
VIDEO
| Resolution | 4MP (2560×1440) |
| Frame Rate | 25/30fps@4MP, 25/30fps@1080P, 25/30fps@720P |
| Video Output | 1-channel BNC high definition video output / CVBS video output (Can switch) |
| Day/Night | Auto (ICR) / Manual |
| OSD Menu | Multi-language |
| BLC Mode | BLC / HLC / DWDR |
| WDR | 120dB |
| Gain Control | AGC |
| Noise Reduction | 2D/3D |
| White Balance | Auto / Manual |
| Smart IR | Auto / Manual |
CERTIFICATIONS
| Certifications | CE (EN55032, EN55024, EN50130-4) |
| FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) | |
| UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
INTERFACE
| Audio Interface | N/A |
GENERAL
| Power Supply | 12V DC ±25% |
| Power Consumption | Max 4.1W (12V DC, IR on) |
| Operating Conditions | -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH/ Start up should be done at above -30°C (-22°F) |
| Ingress Protection & Vandal Resistance | IP67 |
| Material | Alunimium |
| Dimensions | Φ93.4mm×79.4mm (Φ3.68"×3.13") |
| Weight | 0.35kg (0.77lb) |
