- 1/4" 1Megapixel CMOS
- 25/30fps@720P
- High speed, long distance real-time transmission
- HD and SD switchable
- OSD Menu, control over coaxial cable
- DWDR, Day/Night(ICR), AWB, AGC, BLC, 2DNR
- 3.6mm fixed lens (2.8mm optional)
- DC12V
CAMERA
| Image Sensor | 1/2.9″ CMOS |
| Effective Pixels | 1280(H)×720(V), 1MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/50s~1/100000s |
| NTSC: 1/60s~1/100000s | |
| Minimum Illumination | 0.05Lux/F2.8 (Color), 0.005Lux/F2.8 (B/W) |
| S/N Ratio | More than 65dB |
| IR Distance | N/A |
| IR On/Off Control | N/A |
| IR LEDs | N/A |
| Pan | 0° ~ 360° |
| Tilt | 0° ~ 180° |
| Rotation | N/A |
LENS
| Lens Type | Fixed lens / Fixed iris |
| Mount Type | Board-in |
| Focal Length | 3.6mm |
| Max Aperture | F2.8 |
| Angle of View | H: 79,7° |
| Focus Control | N/A |
| Close Focus Distance | 400mm |
| 15,75” |
VIDEO
| Resolution | 720P (1280×720) |
| Frame Rate | 25/30fps@720P |
| Video Output | 1-channel BNC HDCVI high definition video output |
| Day/Night | Auto (Electronic) / Manual |
| OSD Menu | Multi-language |
| BLC Mode | BLC / HLC / DWDR |
| WDR | DWDR |
| Gain Control | AGC |
| Noise Reduction | 2D |
| White Balance | Auto / Manual |
| Smart IR | N/A |
INTERFACE
| Audio Interface | 1- channel audio in |
GENERAL
| Certifications | CE (EN55032, EN55024, EN50130-4) |
| FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) | |
| UL (UL60950-1+CAN/CSA C22.2 No.60950-1) | |
| Power Supply | 12V DC ±10% |
| Power Consumption | Max 1.5W (12V DC, IR on) |
| Operating Conditions | -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH |
| Ingress Protection & Vandal Resistance | N/A |
| Material | Aluminium |
| Dimensions | 35.5mm×30.0mm×21.3mm (1.40"×1.18"×0.84") |
| Weight | 0.05kg (0.11lb) |
