- 1/2.9" 2.0 Megapixel CMOS
- 25/30fps@1080P, 25/30fps@720P
- 12m/110°detectng range/angle
- HD and SD output switchable
- Two level detection sensitivity adjustable
- 2.8mm fxed lens
- Built-in tamper switch
- DC12V
CAMERA
| Image Sensor | 1/2.9″ CMOS |
| Effective Pixels | 1920(H)×1080(V), 2MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/25~1/100000s |
| NTSC: 1/30~1/100000s | |
| Minimum Illumination | 0.02Lux/F2.0(Color), 0.002Lux/F2.0(B/W) |
| S/N Ratio | More than 65dB |
| Pan | 0° ~ 180° |
| Tilt | 0° ~ 180° |
| Rotation | 0° ~ 360° |
LENS
| Lens Type | Fixed lens / Fixed iris |
| Mount Type | Board-in |
| Focal Length | 2.8mm |
| Max Aperture | F2.0 |
| Angle of View | H: 100.5° |
| Focus Control | N/A |
| Close Focus Distance | 500mm |
| 19.7” |
VIDEO
| Resolution | 1080P (1920×1080) |
| Frame Rate | 25/30fps@1080P, 25/30fps@720P |
| Video Output | 1-channel BNC HDCVI high definition video output / CVBS video output (Can switch) |
| Day/Night | Auto (Electronic) / Manual |
| OSD Menu | Multi-language |
| BLC Mode | BLC / HLC / DWDR |
| WDR | DWDR |
| Gain Control | AGC |
| Noise Reduction | 2D |
| White Balance | Auto / Manual |
PIR
| Detection | Passive infrared |
| Detection Range | 12mx12m, 110°, 19 zones |
| Alarm prompt | Red led, can be set to switch off |
| Sensitivity | Two level (jumper) |
| Pet immunity | ≤18Kg |
| Resistance light | 6500LUX |
| Installation height | Defualt bracket, wall mount, 2.2-2.5m |
INTERFACE
| Audio Interface | N/A |
GENERAL
| Certifications | CE (EN55032, EN55024, EN50130-4) |
| FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) | |
| UL (UL60950-1+CAN/CSA C22.2 No.60950-1) | |
| Power Supply | 12V DC ±25% |
| Power Consumption | Max 0.7W (12V DC, IR on) |
| Operating Conditions | -10°C ~ +50°C (+14°F ~ +122°F) / Less than 90% RH |
| Ingress Protection & Vandal Resistance | N/A |
| Material | Plastic |
| Dimensions | 120mm×62mm×58mm (4.72″×2.44″×2.28″) |
| Weight | 0.18kg (0.40lb) |
