CAMERA
| Image Sensor | 1/2.8″ CMOS |
| Effective Pixels | 1937(H)×1097(V), 2.1MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/4s~1/100000s |
| NTSC: 1/3s~1/100000s | |
| Minimum Illumination | 0.005Lux/F1.3, 30IRE, 0Lux IR on |
| S/N Ratio | More than 65dB |
| IR Distance | Up to 60m (197feet) |
| IR On/Off Control | Auto / Manual |
| IR LEDs | 4 |
LENS
| Lens Type | Motorized lens / Fixed iris |
| Mount Type | Board-in |
| Focal Length | 2.7-13.5mm (7-22mm optional) |
| Max Aperture | F1.3 |
| Angle of View | H: 102°~29°(40°~17°) |
| Focus Control | Auto / Manual |
| Close Focus Distance | 200mm(1000mm) |
| 7.87” (39.37”) | |
| Pan/Tilt/Rotation | Pan: 0° ~ 360° |
| Tilt: 0° ~ 87° | |
| Rotation: 0° ~ 360° |
DORI DISTANCE
| Distance | |||
| Wide | Tele | ||
| Detect | 25px/m (8px/ft) | 47m/154ft | 153m/502ft |
| (115m/377ft) | (269m/883ft) | ||
| Observe | 63px/m (19px/ft) | 19m/62ft | 61m/200ft |
| (46m/151ft) | (108m/354ft) | ||
| Recognize | 125px/m (38px/ft) | 9m/30ft | 31m/102ft |
| (23m/75ft) | (54m/177ft) | ||
| Identify | 250px/m (76px/ft) | 5m/16ft | 15m/49ft |
| (12m/39ft) | (27m/89ft) | ||
VIDEO
| Resolution | 1080P (1920×1080) |
| Frame Rate | 25/30fps@1080P, 25/30fps@720P |
| Video Output | 1-channel BNC high definition video output / CVBS video output (Can switch) |
| Day/Night | Auto (ICR) / Manual |
| OSD Menu | Multi-language |
| BLC Mode | BLC / HLC / WDR |
| WDR | 120dB |
| Gain Control | AGC |
| Noise Reduction | 2D/3D |
| White Balance | Auto / Manual |
| Smart IR | Autol / Manual |
CERTIFICATIONS
| Certifications | CE (EN55032, EN55024, EN50130-4) |
| FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) | |
| UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
INTERFACE
| Audio Interface | N/A |
GENERAL
| Power Supply | 12V DC ±25% |
| Power Consumption | Max 10.1W (12V DC, IR on) |
| Operating Conditions | -40°C ~ +60°C (-40°F ~ +140°F) / Less than 90% RH/ Start up should be done at above -40°C (-40°F) |
| Ingress Protection & Vandal Resistance | IP67 |
| Material | Aluminium |
| Dimensions | 213.0mm×90.4mm×90.4mm (8.39″×3.56″×3.56″) |
| Weight | 0.74kg (1.63lb) |
