CAMERA
| Image Sensor | 1/2.8″ CMOS |
| Effective Pixels | 1945(H)×1097(V), 2.1MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1.3s~1/30000s |
| NTSC: 1s~1/30000s | |
| Minimum Illumination | 0.005Lux/F1.4, 30IRE, 0Lux IR on |
| S/N Ratio | More than 65dB |
| IR Distance | Up to 50m (164feet) |
| IR On/Off Control | Auto / Manual |
| IR LEDs | 3 |
LENS
| Lens Type | Motorized lens / Auto iris |
| Mount Type | Board-in |
| Focal Length | 2.7-12mm |
| Max Aperture | F1.4 |
| Angle of View | H: 95°~36° |
| Focus Control | Auto / Manual |
| Close Focus Distance | 300mm |
| 11.81” | |
| Pan/Tilt/Rotation | Pan: 0° ~ 355° |
| Tilt: 0° ~ 65° | |
| Rotation: 0° ~ 355° |
DORI DISTANCE
| Distance | |||
| Wide | Tele | ||
| Detect | 25px/m (8px/ft) | 48m(159ft) | 133m(437ft) |
| Observe | 63px/m (19px/ft) | 19m(64ft) | 53m(175ft) |
| Recognize | 125px/m (38px/ft) | 10m(32ft) | 27m(87ft) |
| Identify | 250px/m (76px/ft) | 5m(17ft) | 13m(44ft) |
VIDEO
| Resolution | 1080P (1920×1080) |
| Frame Rate | 25/30fps@1080P, 25/30/50/60fps@720P |
| Video Output | 1-channel BNC HDCVI high definition video output & 1-channel BNC CVBS video output |
| CVBS tester out | |
| Day/Night | Auto (ICR) / Manual |
| OSD Menu | Multi-language |
| BLC Mode | BLC / HLC / WDR |
| WDR | 120dB |
| Gain Control | AGC |
| Noise Reduction | 2D/3D |
| White Balance | Auto / Manual |
| Smart IR | Autol / Manual |
CERTIFICATIONS
| Certifications | CE (EN55032, EN55024, EN50130-4) |
| FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) | |
| UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
INTERFACE
| Audio Interface | 1-channel audio in |
| Alarm Interface | 1-channel alarm in & 1-channel alarm out |
GENERAL
| Power Supply | AC 24V±25% / DC 12V±25% |
| Power Consumption | Max 12.5W (12V DC, IR on) |
| Operating Conditions | -30°C ~ +60°C (-22°F ~ +140°F) / Less than 90% RH/ Start up should be done at above -30°C (-22°F) |
| Ingress Protection & Vandal Resistance | IP67/ IK10 |
| Material | Aluminium |
| Dimensions | Φ159.1mm×117.9mm (Φ6.26″×4.64″) |
| Weight | 1.20kg (2.65lb) |
