- 1/23" 4.0 Megapixel CMOS
- 25/30fps@4MP, 25/30fps@1080P, 25/30fps@720P
- 10m/110°detectng range/angle
- HD and SD output switchable (video only)
- Quaternionic digital sensor
- 2.8mm fxed lens
- Max. IR LEDs length 20m, Smart IR
- IP67, DC12V
CAMERA
| Image Sensor | 1/3″ CMOS |
| Effective Pixels | 2688(H)×1520(V), 4.1MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/25~1/100000s |
| NTSC: 1/30~1/100000s | |
| Minimum Illumination | 0.03Lux/F2.0(Color), 30IRE, 0Lux IR on |
| S/N Ratio | More than 65dB |
| IR Distance | Up to 20m (66feet) |
| IR On/Off Control | Auto / Manual |
| IR LEDs | 1 |
| Pan | 0° ~ 360° |
| Tilt | 0° ~ 90° |
| Rotation | 0° ~ 360° |
LENS
| Lens Type | Fixed lens / Fixed iris |
| Mount Type | Board-in |
| Focal Length | 2.8mm |
| Max Aperture | F1.8 |
| Angle of View | H: 107.2° |
| Focus Control | N/A |
| Close Focus Distance | 1100mm |
| 43.31” |
VIDEO
| Resolution | 4MP (2560×1440) |
| Frame Rate | 25/30fps@4MP, 25/30fps@1080P, 25/30fps@720P |
| Video Output | 1-channel BNC HDCVI high definition video output / CVBS video output (Can switch) |
| Day/Night | Auto (ICR) / Manual |
| OSD Menu | Multi-language |
| BLC Mode | BLC / HLC / DWDR |
| WDR | DWDR |
| Gain Control | AGC |
| Noise Reduction | 2D |
| White Balance | Auto / Manual |
| Smart IR | Auto / Manual |
PIR
| Detection | Passive infrared |
| Detection Range | 10m, 110° |
| Alarm prompt | Red led |
| Installation height | Defualt bracket, wall mount, 2.2-2.5m |
INTERFACE
| Audio Interface | N/A |
GENERAL
| Certifications | CE (EN55032, EN55024, EN50130-4) |
| FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) | |
| UL (UL60950-1+CAN/CSA C22.2 No.60950-1) | |
| Power Supply | 12V DC ±30% |
| Power Consumption | Max 4.4W (12V DC, IR on) |
| Operating Conditions | -10°C ~ +50°C (+14°F ~ +122°F) / Less than 95% RH |
| Ingress Protection & Vandal Resistance | IP67 |
| Material | Aluminium (Front cover) + Plastic (Rear Barrel) |
| Dimensions | 146.6mm×72.4mm×83mm (5.77″×2.85″×3.27″) |
| Weight | 0.30kg (0.66lb) |
