- Up to 4.0 megapixel high resolution
- Support H.264+, Dual stream, Backlight Compensation
- Full HD 1080p, 120db WDR, 3D DNR
- EXIR high performance LEDs, PoE
- IP67, 3-axis adjustment
- Up to 30m IR range
CAMERA
| Image Sensor | 1/3" Progressive Scan CMOS |
| Min. Illumination | 0.01Lux @(F1.2,AGC ON), 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Lens | 2.8mm, 4mm, 6mm @ F2.0 |
| Angle of view | 109.4°(2.8mm), 90°(4mm), 53.9°(6mm) |
| Lens Mount | M12 |
| Day &Night | IR cut filter with auto switch |
| DNR | 3D DNR (Digital Noise Reduction) |
| Wide Dynamic Range | Digital WDR 120dB |
| Angle Adjustment | Pan:0° ~ 360°, Tilt: 0° ~ 75°, Rotation: 0° ~ 360° |
COMPRESSION STANDARD
| Video Compression | H.264 / MJPEG/H.264+ |
| H.264 Type | Main Profile |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| Dual Stream | Support |
| Max. Resolution | 2688 × 1520 |
| Frame Rate | 20 fps (2688 × 1520); 30 fps (1920 × 1080), (1280 × 720) |
| Backlight Compensation | Support, zone configurable |
| Image Setting | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
| ROI Codec | Support |
NETWORK
| Network Storage | NAS (Support NFS,SMB/CIFS), ANR |
| Detection | Intrusion detection, Line crossing detection, Motion detection, Dynamic analysis |
| Alarm Trigger | Tampering alarm, Network disconnect, IP address conflict, Storage exception |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Standard | ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| General Function | Three level user authentication, password authorization, HTTPS and SSH certificate, IEEE802.1X, basic and digest authentication, watermark, IP address filtering, log-in lockout |
INTERFACE
| Communication Interface | 1 RJ45 10M/100M Ethernet port |
GENERAL
| Working | -30 °C to 60 °C (-22 °F to 140 °F) |
| Temperature/Humidity | Humidity 95% or less (non-condensing) |
| Power Supply | 12V DC ± 10%, PoE (802.3af, class 3) |
| Power Consumption | Max. 5.5W; with ICR on: Max. 7.5W |
| Weather Proof Ratings | IP67 |
| IR Range | 30 meters |
| Material | Plastic & Metal |
| Dimension | Φ127×97.5 (5.0” × 3.8”) |
| Weight | 670g (1.5 lb) |
