- Up to 4.0 megapixel high resolution
- WDR 120dB, 3D DNR
- Support dual stream, H.264+, Up to 30m IR range
- IR cut filter with auto switch, PoE
- IP67, IK10
- Bit rate mode: CBR and VBR
- Support on-board storage, up to 128GB
- Audio/Alarm IO
- Built-in Wi-Fi
CAMERA
| Image Sensor | 1/3" Progressive Scan CMOS |
| Min. Illumination | 0.05Lux @ (F1.2, AGC ON) in the color mode |
| 0.01Lux @ (F1.2, AGC ON) in B/W mode, 0 Lux with IR | |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Lens | 2.7mm, 4mm, 6mm @ F2.0 |
| Angle of view | 106°(2.7mm), 83°(4mm), 55.4°(6mm) |
| Lens Mount | M12 |
| Day &Night | IR cut filter with auto switch |
| DNR | 3D DNR (Digital Noise Reduction) |
| White Balance | Automatic/Manual |
| Wide Dynamic Range | Digital WDR 120dB |
| P&T rotation | Pan:0° - 355°, Tilt: 0° - 75°, Rotation: 0-355° |
COMPRESSION STANDARD
| Video Compression | H.264 / MJPEG/H.264+ |
| H.264 Type | Main Profile |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| Dual Stream | Yes |
| Max. Resolution | 2688×1520 |
| Max Frame Rate 60Hz | Main stream:20fps(2688×1520), 25fps (2048x1536), 30fps(1920×1080), 30fps (1280x960), 30fps(1280×720) |
| Sub stream: 30fps(352×240),30fps(704×480) | |
| Backlight compensation |
Yes, zone optional |
| Image Setting | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser and AGC |
| ROI Codec | Support |
NETWORK
| Network Storage | NAS (Support NFS,SMB/CIFS), ANR |
| Detection | Intrusion detection, Line crossing detection, Motion detection, Dynamic analysis |
| Alarm Trigger | Tampering alarm, Network disconnect, IP address conflict, Storage exception |
| Protocols | IPV4 and IPV6, TCP/IP, UDP, ICMP, HTTP, HTTPS, SSL, DHCP, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, ARP |
| Standard | ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| General Function | Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access, log access of the user, 10 simultaneous connection. |
INTERFACE
| Communication Interface | 1 RJ45 10M/100M Ethernet port, Base T |
| On-board storage | Built-in Micro SD/SDHC/SDXC slot, up to 128GB |
| Reset Button | Yes |
| Alarm interface | 1x alarm I/O |
| Audio interface | 1x audio I/O |
WIFI SPECIFICATION
| Wireless Standards | IEEE802.11b, 802.11g, 802.11n |
| Frequency Range | 2.4 GHz – 2.4835 GHz |
| Channel Bandwidth | 20/40MHz Support |
| Protocols | 802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM |
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Transfer Rates | 11b: 11Mbps; 11g: 54Mbps; 11n: up to 150Mbps |
| Wireless Range | 50 meters (The performance varies based on actual environment) |
GENERAL
| Working | -30 °C to 60 °C (-22 °F to 140 °F) |
| Temperature/Humidity | Humidity 95% or less (non-condensing) |
| Power Supply | 12V DC ± 25%, PoE (802.3af, class 3) |
| Power Consumption | Max. 4W with the IR in ON |
| Weather Proof Ratings | IP67 |
| Impact Protection | IK10 |
| IR Range | 30 meters |
| Material | Plastic & Metal |
| Dimension | Φ 111 × 82 mm (Φ 4.4″ × 3.2″) |
| Weight | 500g (1.1 lb) |
