- 1/4” Progressive Scan CMOS
- Up to 1 megapixel high resolution
- 30 m IR range, dual stream, digital WDR, 3D DNR
- IP66 weather-proof protection
- Mobile Monitoring via Hik-Connect or iVMS-4500
- Login security protection and password strength
detection
CAMERA
| Image Sensor | 1/4" Progressive Scan CMOS |
| Min. Illumination | 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/100,000 s, support slow shutter |
| Lens | 4mm |
| Horizontal field of view | 73.1° (6mm,8mm,12mm optional) |
| Lens Mount | M12 |
| Day &Night | IR cut filter with auto switch |
| DNR | 3D DNR (Digital Noise Reduction) |
| Wide Dynamic Range | Digital WDR |
COMPRESSION STANDARD
| Video Compression | H.264, MJPEG |
| H.264 Type | Baseline Profile/Main Profile |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| Dual Streams | Support |
| Max. Resolution | 1280×720 |
| Main Stream | 50Hz: 1280×720@25fps |
| 60Hz: 1280×720@30fps | |
| Sub-stream | 50Hz: 704×576@25fps |
| 60Hz: 704×576@30fps | |
| Others | Mirror, BLC (area configurable), Brightness, Contrast, Saturation |
NETWORK
| Alarms | Motion Detection, Dynamic Analysis, Video Tampering, Network Disconnected, IP Address Conflicted |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Standard | ONVIF,PSIA,CGI,ISAPI |
| General Function | Anti-Flicker, Dual Stream, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark |
INTERFACE
| Communication Interface | 1 RJ45 10M/100M Ethernet port |
GENERAL
| Working | -30 °C to 60 °C (-22 °F to 140 °F) |
| Temperature/Humidity | Humidity 95% or less (non-condensing) |
| Power Supply | DC12V ± 10% |
| Power Consumption | Max. 4.5W; with pan and tilt: Max. 9W |
| Weather Proof Ratings | IP66 |
| Material | Plastic |
| IR Range | 50 meters |
| Dimension | 147.5mm×78.2mm×92.9mm (5.8"×3.1"×3.7") |
| Weight | 350g (0.8 lb) |
| Accessory | DS-1296ZJ Wall-Mounted Bracket (Included) |
