CAMERA
Image Sensor | 1/4" Progressive Scan CMOS |
Min. Illumination | 0.01Lux @ (F1.2, AGC ON) , 0.028Lux @ (F2.0, AGC ON) , 0 Lux with IR |
Shutter Speed | 1/3 s ~ 1/100,000 s |
Lens | 4mm@ F2.0 |
Angle of view | 73.1° (2.8/6/8/12mm optional) |
Lens Mount | M12 |
Day &Night | IR cut filter with auto switch |
Angle Adjustment | Pan:0° - 360°, Tilt: 0° - 75°, Rotation: 0° - 360° |
Wide Dynamic Range | Digital WDR |
COMPRESSION STANDARD
Video Compression | H.264, MJPEG |
H.264 Type | Baseline Profile/Main Profile |
Video Bit Rate | 32 Kbps to 8 Mbps |
Max. Resolution | 1280×720 |
Frame Rate | 50Hz: 1280×720@25fps |
60Hz: 1280×720@30fps | |
Image Enhancement | BLC/3D DNR |
Image Setting | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
NETWORK
Alarm Trigger | Motion Detection, Dynamic Analysis, Video Tampering, Network Disconnected, IP Address Conflicted, Storage exception |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
Standard | ONVIF,PSIA,CGI,ISAPI |
Security | Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, anonymous access |
INTERFACE
Communication Interface | 1 RJ45 10M/100M Ethernet port |
GENERAL
Working | -10 °C – 40 °C (14 °F – 104 °F) |
Temperature/Humidity | Humidity 95% or less (non-condensing) |
Power Supply | DC12V ± 10% |
Power Consumption | Max. 3.2W |
Weather Proof Ratings | |
Material | Plastic |
IR Range | 10 meters |
Dimension | Φ110 × 80.9 mm |
Weight | 190g (0.42 lb) |
