- Up to 2.0 megapixel high resolution
- WDR, 3D DNR, Backlight Compensation
- The bit rate mode: CBR and VBR
- IR range: up to 30m
- Auto Electronic Shutter
- IP67, IK10, PoE
- Built-in Micro SD/SDHC/SDXC card slot, up to 128 GB
- Motorized varifocal lens for easy remote focusing
CAMERA
| Image Sensor | 1/3" Progressive Scan CMOS |
| Min. Illumination | 0.05Lux @ (F1.2, AGC ON) in color mode and 0.01Lux @ (F1.2, AGC ON) in black and white, 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/100,000 s |
| Lens | 2.8 ~ 12 mm @F1.4 |
| Lens Drive Type | Motorized Zoom & Focus |
| Horizontal field of view | 113° (Wide) ~ 33.8° (Tele) |
| Lens Mount | Φ14 |
| Day &Night | IR cut filter with auto switch |
| DNR | 3D DNR (Digital Noise Reduction) |
| Wide Dynamic Range | Digital WDR 120dB |
| White balance | Automatic/Manual |
| 3-Axis Adjustment | Pan: 0° to 355°, Tilt: 0° to 75°, Rotation: 0° to 355° |
COMPRESSION STANDARD
| Video Compression | H.264 / MJPEG |
| H.264 Type | Baseline Profile/Main Profile |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| Dual Streams | Support |
| Max. Resolution | 1920 × 1080 |
| Max Frame Rate | 50Hz: 25fps (1920 × 1080,1280 × 1024,1280 x 960,1280 × 720) |
| 60Hz: 30fps (1920 × 1080,1280 × 1024, 1280 x 960,1280 × 720) | |
| Sub Stream | 50 Hz: 25 fps (320 x 240), 25 fps (352 x 288), 25 fps (640 x 480), 25fps(704 x 576) |
| 60 Hz: 30 fps (320 x 240), 30 fps (352 x 240), 30 fps (640 x 480), 30fps(704 x 480) | |
| Image Setting | Saturation, Brightness, Contrast, etc., adjustable by client software or web browser |
| Backlight Compensation | Support, zone optional |
| ROI Codec | Support one customized region for each stream |
NETWORK
| Network Storage | Support Micro SD/SDHC/SDXC card (up to 128 GB) local storage and NAS (NFS,SMB/CIFS) |
| Detection | Intrusion Detection, Line Crossing Detection, Motion Detection, Dynamic Analysis |
| Alarm Trigger | Video Tempering Detection, Network Disconnected, IP Address Conflicted, HDD Full, HDD Error |
| Protocols | IPV4 and IPV6, TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, SSL, PPPoE, SNMP, ARP, filter IP |
| Standard | ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| General Function | Anti-Flicker, Mirror, Password Protection, Privacy Mask, Watermark, Heartbeat, AGC, log access and 10 simultaneous access |
INTERFACE
| Communication Interface | 1 RJ45 10M/100M Ethernet port/ Base T |
| Onboard storage | Built-in Micro SD / SDHC / SDXC card slot, up to 128 GB |
GENERAL
| Working | -30 °C to 60 °C (-22 °F to 140 °F) |
| Temperature/Humidity | Humidity 95% or less (non-condensing) |
| Power Supply | 12V DC ± 10%, PoE (802.3af) |
| Power Consumption | Max. 5.5W with ICR on |
| Weather Proof Ratings | IP67, IK10 |
| IR Range | 30 meters with smart IR |
| Material | Metal & Plastic |
| Dimension | Φ141 × 99.9 mm (5.55” × 3.94”) |
| Weight | 800g (1.76 lbs) |
