- 1/2.8” Progressive Scan CMOS
- Up to 2.0 megapixel high resolution
- 30 m IR range, dual stream, digital WDR, 3D DNR
- IP67 weather-proof protection
- Mobile Monitoring via Hik-Connect or iVMS-4500
- PoE
CAMERA
Image Sensor | 1/2.8" Progressive Scan CMOS |
Min. Illumination | 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR |
Shutter Speed | 1/3 s to 1/100,000 s, support slow shutter |
Lens | 2.8 mm @F2.0, 4 mm @F2.0, 6 mm @F2.0, |
Horizontal field of view | 2,8mm: 95°, 4mm: 83.6°, 6mm: 55° |
Lens Mount | M12 |
Day &Night | IR cut filter with auto switch |
3-Axis Adjustment | Pan: 0° to 360°, tilt: 0°to 75°, rotation:0° to 360° |
DNR | 3D DNR (Digital Noise Reduction) |
Wide Dynamic Range | Digital WDR |
COMPRESSION STANDARD
Video Compression | Main stream: H.264+/H.264 |
Sub stream: H.264, MJEPG | |
H.264 Type | Baseline Profile/Main Profile |
Video Bit Rate | 32 Kbps to 8 Mbps |
Dual Streams | Support |
Max. Resolution | 1920 × 1080 |
Main Stream Max.Frame Rate | 50Hz: 1920 × 1080,1280 × 960,1280 × 720 @25fps |
60Hz: 1920 × 1080,1280 × 960,1280 × 720 @30fps | |
Sub-stream Max.Frame Rate | 50Hz: 704 × 576, 640 × 480, 352 × 288, 320 × 240 @25fps |
60Hz: 704 × 480, 640 × 480, 352 × 240, 320 × 240 @30fps | |
Image Settings | Brightness, saturation, contrast, sharpness are adjustable via web browser or client software |
Day/Night Switch | Support auto, scheduled |
Others | Mirror, BLC (area configurable), Region of Interest (support 1 fixed region) |
NETWORK
Network Storage | NAS (NFS,SMB/CIFS) |
Alarms | Motion Detection, Dynamic Analysis, Video Tampering, Network Disconnected, IP Address Conflicted |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
Standard | ONVIF(PROFILE S,PROFILE G),PSIA,CGI,ISAPI |
General Function | Anti-Flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, IP Address Filter, Watermark |
INTERFACE
Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
GENERAL
Working | -30 °C to 60 °C (-22 °F to 140 °F) |
Temperature/Humidity | Humidity 95% or less (non-condensing) |
Power Supply | DC12V ± 25%, PoE (802.3af) |
Power Consumption | Max. 4W |
Weather Proof Ratings | IP67 |
Material | Plastic |
IR Range | 30 meters |
Dimension | Φ 85.5 mm × 70 mm (3.38"× 2.76") |
Weight | 350g (0.77 lb) |
