- 1/2.8” Progressive Scan CMOS
- Up to 2.0 megapixel high resolution
- 30 m IR range, dual stream, digital WDR, 3D DNR
- IP67 weather-proof protection
- Mobile Monitoring via Hik-Connect or iVMS-4500
- PoE
CAMERA
| Image Sensor | 1/2.8" Progressive Scan CMOS |
| Min. Illumination | 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR |
| Shutter Speed | 1/3 s to 1/100,000 s, support slow shutter |
| Lens | 4mm |
| Horizontal field of view | 83° (6mm: 55°, 8mm: 38.5°, 12mm: 24.6°, optional) |
| Lens Mount | M12 |
| Day &Night | IR cut filter with auto switch |
| DNR | 3D DNR (Digital Noise Reduction) |
| Wide Dynamic Range | Digital WDR |
COMPRESSION STANDARD
| Video Compression | Main stream: H.264 |
| Sub stream: H.264, MJEPG | |
| H.264 Type | Baseline Profile/Main Profile |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| Dual Streams | Support |
| Max. Resolution | 1920 × 1080 |
| Main Stream Max.Frame Rate | 50Hz: 1920 × 1080,1280 × 960,1280 × 720 @25fps |
| 60Hz: 1920 × 1080,1280 × 960,1280 × 720 @30fps | |
| Sub-stream Max.Frame Rate | 50Hz: 704 × 576, 640 × 480, 352 × 288, 320 × 240 @25fps |
| 60Hz: 704 × 480, 640 × 480, 352 × 240, 320 × 240 @30fps | |
| Image Settings | Brightness, saturation, contrast, sharpness are adjustable via web browser or client software |
| Day/Night Switch | Support auto, scheduled, and triggered by alarm input |
| Others | Mirror, BLC (area configurable), Region of Interest (support 1 fixed region) |
NETWORK
| Alarms | Motion Detection, Dynamic Analysis, Video Tampering, Network Disconnected, IP Address Conflicted, HDD Full, HDD Error |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Standard | ONVIF(PROFILE S,PROFILE G),PSIA,CGI,ISAPI |
| General Function | Anti-Flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, IP Address Filter, Watermark |
INTERFACE
| Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
GENERAL
| Working | -30 °C to 60 °C (-22 °F to 140 °F) |
| Temperature/Humidity | Humidity 95% or less (non-condensing) |
| Power Supply | DC12V ± 25%, PoE (802.3af) |
| Power Consumption | Max. 3.5W |
| Weather Proof Ratings | IP67 |
| Material | Plastic |
| IR Range | 30 meters |
| Dimension | 147.5mm×78.2mm×92.9mm (5.8"×3.1"×3.7") |
| Weight | 350g (0.8 lb) |
| Accessory | DS-1296ZJ Wall-Mounted Bracket (Included) |
