- Up to 4.0 megapixel high resolution - Full HD1080p
- 4mm/6mm fixed lens, 120dB Wide Dynamic Range
- 3D Digital Noise Reduction, Backlight Compensation
- Support dual stream, PoE (Power over Ethernet), IP66
- Approx. 30 meters IR range
- 3-axis adjustment
CAMERA
Image Sensor | 1/3" Progressive Scan CMOS |
Min. Illumination | 0.01Lux @ (F1.2, AGC ON), 0 Lux with IR |
Shutter Speed | 1/3 s to 1/100,000 s |
Lens | 4mm, 6mm@ F2.0 |
Angle of view | 83° (4mm). 55,4°(6mm) |
Lens Mount | M12 |
Day &Night | IR cut filter with auto switch |
DNR | 3D DNR (Digital Noise Reduction) |
Wide Dynamic Range | Digital WDR 120dB |
COMPRESSION STANDARD
Video Compression | H.264 / MJPEG/H.264+ |
H.264 Type | Main Profile |
Video Bit Rate | 32 Kbps to 16 Mbps |
Dual Stream | Yes |
Max. Resolution | 2688×1520 |
Frame Rate | 50Hz: 20fps (2688×1520), 25fps(1920×1080), 25fps(1280×720) |
60Hz: 20fps (2688×1520), 30fps (1920×1080), 30fps(1280×720) | |
Image Setting | Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser |
Backlight Compensation | Yes, zone configurable |
ROI Code | Support |
NETWORK
Network Storage | NAS (Support NFS,SMB/CIFS), ANR |
Alarm Trigger | Motion detection, Tampering alarm, Network disconnect, IP address conflict, Storage exception |
Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
Standard | ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
General | One-key reset, Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access |
INTERFACE
Communication Interface | 1 RJ45 10M/100M Ethernet port |
GENERAL
Working | -30 °C to 60 °C (-22 °F to 140 °F) |
Temperature/Humidity | Humidity 95% or less (non-condensing) |
Power Supply | 12V DC ± 10%, PoE (802.3af) |
Power Consumption | Max. 5W |
Weather Proof Ratings | IP66 |
IR Range | 30m |
Material | Metal |
Dimension | 70x154.2x60.5mm (2.8"x6.2"x2.4") |
Weight | 500g (1.1 lb) |
